P-Audio SN6-150CX - 6" 150W 8/8 Ohm
SPL: 92.1dB Fs: 71Hz Xmax: 3.8mm
Product Code: PAUSN6150CX | Brand: P-Audio
P-Audio SN6-150CX - 6 inch 150W 8/8 Ohm

P-Audio SN6-150CX - 6 inch 150W 8/8 Ohm P-Audio SN6-150CX - 6 inch 150W 8/8 Ohm P-Audio SN6-150CX - 6 inch 150W 8/8 Ohm
£55.68 ex VAT
Login to see JAM Club pricing
Not a member? Join Now
£7.52 DELIVERY to mainland UK
P-Audio SN6-150CX - 6" 150W 8/8 Ohm

The P Audio SN6-150CX is a high performance coaxial transducer. The SN6-150CX is an upgraded design that features many of P Audios new technologies and performance upgrades. The low frequency section utilizes a large diameter voice coil design while the high frequency section employs a medium format titanium diaphragm assembly. The 6.5 inch (165mm) diameter piston will produce extremely high sound pressure levels at both low and mid band frequencies and is ideal for high level response in both live sound and recorded music venues. The transducer uses very high energy ferrite magnetics to achieve a very high acoustic output to weight ratio. The SN6-150CX has been optimized for use in two way or three way sound reinforcement systems and has an operating range of 60Hz to 20000Hz. The SN6-150CX features a 1.75 inch (44.5mm) diameter voice coil that provides an AES rated 150 watts of continuous power handling and a full 600 watts of peak rated power handling when sufficient amplifier headroom is available. The SN6-150CX employs P Audios under damper venting to control turbulent air flow. The voice coil design is a bobbin wound geometry with P Audios precision round wire technology to maximize system conversion efficiency. The high frequency section is a close spaced titanium diaphragm assembly. The diaphragm is a 1.34 inch (34mm) diaphragm that provides excellent high frequency response and superior power handling and durability. The horn loading is a thru pole piece design The overall high frequency design provides very high sensitivity. The transducer chassis is a die cast aluminum design that ensures a very high degree of structural integrity.

General Specifications:

  • Nominal diameter - 165 mm/6.5 in
  • Power rating - 150 W(AES)
  • Nominal impedance - 8
  • Sensitivity - 93 dB
  • Frequency range - 60-20000 Hz
  • Chassis type - Cast aluminum
  • Magnet type - Ferrite
  • Magnet weight - 0.85 kg/29.9 oz
  • Voice coil diameter - 44.5 mm/1.75 in
  • Coil material - CCA-W/AL-R
  • Former material - Kapton
  • Cone material - Paper
  • Surround material - Rubber
  • Suspension - Single
  • X-max - 3.75 mm/0.15 in
  • Gap depth - 6 mm/0.24 in
  • Voice coil winding width - 13.5 mm/0.53 in
  • Net Weight - 3 kg/6.6 lb
  • Packing Dimension WxDxH - 170 x 170 x 160 mm
  • Shipping Weight - 170 x 170 x 160 mm

Small Signal Parameters:

  • Re - 5.5
  • Fs - 71 Hz
  • Mms - 12.88 g/0.45 oz
  • Mmd - 11.91 g/0.42 oz
  • Qms - 5.17
  • Qes - 0.40
  • Qts - 0.37
  • Vas - 11.2 lt/0.39 ft
  • BI - 8.94 Tm
  • Cms - 3.9e-04 m/N
  • Rms - 1.11 Ns/m
  • Le (at 1kHz) - 0.42 mH
  • Sd - 143 cm2
