Unleash the Power
The FaitalPRO 21XL3000 represents the pinnacle of modern low-frequency driver design. Built for extreme output, precision, and durability, it is the ultimate choice for professional systems where nothing less than uncompromising bass performance will do.
The FaitalPRO 21XL3000 is a no-compromise 21" high-power neodymium subwoofer, engineered for professional audio systems where deep, controlled, and extremely high-output low frequencies are essential.
Designed for touring sound systems, arenas, large-scale outdoor events, premium clubs, and high-end cinema or theatre installations, the 21XL3000 delivers exceptional SPL, clarity, and reliability even under the most demanding operating conditions.
With a massive 3000 W AES power rating and up to 6000 W maximum/program power handling, this driver is built to move serious air while maintaining tight control and low distortion. The result is powerful, chest-impacting bass that is felt as much as it is heard.
The FEA-optimised neodymium motor assembly achieves an exceptional magnetic flux density of 1.4 T and an impressive BL factor of 43 N/A, delivering outstanding motor force and control. An integrated aluminium demodulation ring minimises inductance variation, reducing distortion and ensuring clean, accurate low-frequency reproduction at high output levels.
Key Highlights
- 3000 W AES / 6000 W maximum power handling
- 21" high-output professional subwoofer driver
- 165 mm (6.5") dual-layer aluminium voice coil
- FEA-optimised neodymium motor with 1.4 T flux density
- Low distortion design with aluminium demodulation ring
- Triple-roll surround for high excursion and durability
- Ultra-rigid, weather-resistant cone construction
- Designed for touring, festival, club, and cinema applications
| Nominal Diameter | 535 mm (21 in) |
| Overall Diameter | 547 mm (21.45 in) |
| Baffle Cutout Diameter | 508 mm (20.00 in) |
| Bolt Circle Diameter | 527 mm (20.75 in) |
| Depth | 274 mm (10.79 in) |
| Net Weight | 21.5 kg (47.4 lb) |
| Enclosure Air Volume | 13.0 dm3 (0.459 ft3) |
Electrical & Performance Specifications
| Nominal Impedance | 8 Ω |
| Minimum Impedance | 7 Ω |
| AES Power Handling | 3000 W |
| Maximum / Program Power | 6000 W |
| Sensitivity (1 W / 1 m) | 98 dB |
| Frequency Range | 30-1500Hz |
Thiele-Small Parameters
| Fs | 30 Hz |
| Re | 5.9 Ω |
| Qes | 0.25 |
| Qms | 8.8 |
| Qts | 0.25 |
| Vas | 284.6 dm3 (10.05 ft3) |
| Sd | 1744 cm2 |
| Xmax | 17.67 mm |
| Xdamage | 40 mm |
| BL | 43 N/A |
| Le | 1.25 mH |
| Efficiency (η0) | 1.8 % |
| EBP | 119 Hz |
| Other products similar to Faital Pro 21XL3000 - 21" 3000W 8 Ohm Loudspeaker: |
|
If you find 'Faital Pro 21XL3000 - 21" 3000W <span class="ohm_8">8 Ohm</span> Loudspeaker' at a lower price from an authorised UK dealer, tell us and we'll aim to match it. Request a price match. Terms & Conditions.
Faital Pro 21XL3000 - 21" 3000W 8 Ohm Loudspeaker PDF data sheet (2 Mb)
