Eminence Legend EM12 A 12" Speaker 200W 8 Ohm Guitar Loudspeaker Driver


Product Code: EMILEGEM12A | Brand: Eminence
Eminence Legend EM12 A 12 inch Speaker 200W 8 Ohm Guitar Loudspeaker Driver

Eminence Legend EM12 A 12 inch Speaker 200W 8 Ohm Guitar Loudspeaker Driver Eminence Legend EM12 A 12 inch Speaker 200W 8 Ohm Guitar Loudspeaker Driver Eminence Legend EM12 A 12 inch Speaker 200W 8 Ohm Guitar Loudspeaker Driver Eminence Legend EM12 A 12 inch Speaker 200W 8 Ohm Guitar Loudspeaker Driver
£154.08
£128.40 ex VAT
2-3 £151.77 ea.4-7 £149.46 ea.8+ £146.38 ea.
Login to see JAM Club pricing
Not a member? Join Now
£9.12 DELIVERY to mainland UK.
Eminence Legend EM12 A 12" Speaker 200W 8 Ohm Guitar Loudspeaker Driver

A high power 12 inch guitar speaker featuring ultra-clean tone with big, round, punchy lows and warm, smooth mids and highs. A more neutral tone so you can hear more of your amp and guitar.

Specifications:

  • Nominal Basket Diameter 12", 305mm
  • Nominal Impedance 8 ohms
  • Power Rating - Watts (AES) 200W, Music Program N/A
  • Resonance 49Hz
  • Usable Frequency Range 60Hz - 4.9kHz
  • Sensitivity 101.1dB
  • Magnet Weight 80 oz.
  • Gap Height 0.375", 9.5mm
  • Voice Coil Diameter 2.5", 64mm


Thiele Small Parameters:

  • Resonant Frequency (fs) 49Hz
  • DC Resistance (Re) 6.6
  • Coil Inductance (Le) 0.49mH
  • Mechanical Q (Qms) 7.39
  • Electromagnetic Q (Qes) 0.29
  • Total Q (Qts) 0.28
  • Compliance Equivalent Volume (Vas) 102.31 liters / 3.61 cu.ft.
  • Peak Diaphragm Displacement Volume (Vd) 0cc
  • Mechanical Compliance of Suspension (Cms) 0.26mm/N
  • BL Product (BL) 16.9 T-M
  • Diaphragm Mass Inc. Airload (MMs) 40 grams
  • Efficiency Bandwidth Product (EBP) 170
  • Maximum Linear Excursion (Xmax) 1.3mm
  • Surface Area of Cone (Sd) 532.4 cm2
  • Maximum Mechanical Limit (Xlim) N/A


Mounting Information:

  • Recommended Enclosure Volume: Sealed Acceptable Vented Acceptable
  • Driver Volume Displaced 155.5 cu.in. / 2.55 liters
  • Overall Diameter 12.38", 314.5mm
  • Baffle Hole Diameter 11.07", 281.2mm
  • Front Sealing Gasket Yes
  • Rear Sealing Gasket Yes
  • Mounting Holes Diameter 0.26", 6.6mm
  • Mounting Holes B.C.D. 11.57", 293.9mm
  • Depth 5.38", 136.5mm
  • Net Weight 16.3 lbs, 7.39 kg
  • Shipping Weight 18 lbs, 8.16 kgs


Materials Of Construction:

  • Coil Construction Edge wound aluminum voice coil
  • Coil Former Polyimide former
  • Magnet Composition Ferrite magnet
  • Core Details Vented core
  • Basket Materials Die cast aluminium basket
  • Cone Composition Paper cone
  • Cone Edge Composition Paper cloth edge
  • Dust Cap Composition Paper dust cap
