Beyma 12MCB700 - 12" 700W 8 Ohm
SPL: 98dB Fs: 51Hz Xmax: 7.0mm

Product Code: BMA12MCB700 | Brand: Beyma
Beyma 12MCB700 - 12 inch 700W 8 Ohm

Beyma 12MCB700 - 12 inch 700W 8 Ohm Beyma 12MCB700 - 12 inch 700W 8 Ohm
£141.52
£117.93 ex VAT
Qty:
3-9 £133.66 ea.10-19 £132.31 ea.20+ £130.95 ea.
Login to see JAM Club pricing
Not a member? Join Now
£2.51 DELIVERY to mainland UK
Beyma 12MCB700 - 12" 700W 8 Ohm

  • High power handling: 1.400 W program power
  • Exclusive Malt Cross® Technology Cooling System
  • Low power compression losses
  • High sensitivity: 98 dB (1W / 1m)
  • FEA optimized magnetic circuit
  • Optimized non-linear behaviour
  • Waterproof cone treatment on both sides of the cone
  • 3” DUO double layer in/out copper voice coil
  • Aluminium demodulating ring
  • Extended controlled displacement: Xmax ± 7 mm
  • 45 mm peak-to-peak excursion before damage
  • Optimized for low frequency and mid-bass applications

Technical Specifications


  • Nominal impedance 8 Ohm
  • Power capacity 700 W AES
  • Nominal diameter 300 mm 12 in
  • Sensitivity 98 dB 1 W/1 m @ ZN
  • Minimum impedance 7.1 ohm
  • Frequency range 55-4000 Hz
  • Program power 1400 W
  • Recommended enclosure volume 40 l
  • Voice coil diameter 76.2 mm 3 in
  • BL factor 20.4 N/A
  • Moving mass 0.069 kg
  • Winding length 18 mm
  • Air gap height 9.5 mm
  • Xdamage pp 45 mm

Thiele Small Parameters:


  • Fs 51 Hz
  • Re 5.4 ohm
  • Qms 3.9
  • Qes 0.29
  • Qts 0.27
  • Vas 59.5 l
  • Cms 139 µm / N
  • Rms 5.6 kg / s
  • Efficiency % 2.7
  • Sd 0.055 m²
  • Xmax 7 mm
  • Vd 385 cm³
  • Le @1 kHz 0.9 mH

Mounting Information


  • Overall diameter 312 mm 12.3 in
  • Bolt circle diameter 295 mm 11.6 in
  • Baffle cutout diameter 278 mm 10.9 in (front-mount)
  • Depth 145 mm 5.7 in
  • Net weight 7.8 kg 17.2 lb
  • Shipping weight 9.5 kg 20.9 lb
