Faital Pro 12FH500 12 inch 500W 4 Ohms
With Push-button Spring Terminals

Product Code: FTP12FH500CP | Brand: Faital Pro | Model: 12FH500 4 Ohm Push


£146.88
£122.40 ex VAT
Login to see JAM Club pricing
Not a member? Join Now
Mainland UK DELIVERY:
£3.64
European Delivery Prices
Usually available
in 5-7 weeks


Request Stock Info

Qty:
Faital Pro 12FH500 12" 500W 4 Ohms

Nominal Specifications


  • Nominal Diameter - 300 mm (12 in)
  • Overall Diameter - 316 mm (12.44 in)
  • Bolt Circle Diameter - 298.5 mm (11.75 in)
  • Baffle Cutout Diameter - 284 mm (11.18 in)
  • Depth - 155.75 mm (6.13 in)
  • Flange and Gasket Thickness - 12.45 mm (0.49 in)
  • Net Weight - 3.9 Kg (8.6 lb)
  • Shipping Box(Single Carton Box) - 350 x 346 x 216 mm (13.8 x 13.6 x 8.5 in)
  • Shipping Weight - 5 Kg (11.02 lb)

Technical Parameters


  • Nominal Impedance - 4 Ohm
  • Minimum Impedance - 4 Ohm
  • AES Power Handling (1) - 500 W
  • Maximum Power Handling (2) - 1000 W
  • Sensitivity (1W/1m) - 97 dB
  • Frequency Range - 45-4000 Hz
  • Voice Coil Diameter - 77 mm (3 in)
  • Winding Material - Al
  • Former Material - Glass Fiber
  • Winding Depth - 18 mm (0.71 in)
  • Magnetic Gap Depth - 10.5 mm (0.41 in)
  • Flux Density - 1.2 T
  • Magnet - Neodymium Slug
  • Basket Material - Aluminum
  • Demodulation - No
  • Cone Surround (3) - M-Roll
  • NET Air Volume filled by Loudspeaker - 2.3 l (0.081 ft^3)
  • Spider Profile - 1x variable height waves

Thiele and small parameters


  • Fs - 45 Hz
  • Re - 3.3 Ohm
  • Qes - 0.23
  • Qms - 9.09
  • Qts - 0.23
  • Vas - 69.1 l (2.44 ft^3)
  • Sd - 487 cm^2 (75.5 in^2)
  • Xmax (4) - 7.25 mm
  • Xdamage (5) - 16 mm
  • Mms - 60.9 g
  • Bl - 15.5 N/A
  • Le - 0.63 mH
  • Mmd - 54.7 g
  • Cms - 0.2 mm/N
  • Rms - 1.89 Kg/s
  • Eta Zero - 2.58 %
  • EBP - 196 Hz
