P-Audio PA-DE34 30W 1 inch Throat Compression Driver

Product Code: PAUPADE34 | Brand: P-Audio | Model: PA-DE34


£29.45
Login to see JAM Club pricing
Not a member? Join Now
Mainland UK DELIVERY:
£6.66
European Delivery Prices
9
IN STOCK

Qty:
P-Audio PA-DE34 30W 1" Throat Compression Driver

The P Audio PA-DE34 is a small format diaphragm compression driver designed for mid range and extended high frequency applications in two way professional sound reinforcement systems. The small format design is excellent for wide bandwidth applications and is ideal for medium sized sound reinforcement systems using 8 inch 203mm) and 10 inch (254mm) woofers. The driver has a rated bandwidth of 1.2kHz to beyond 20kHz. This wide bandwidth makes the PA-DE34 ideal for many mid range applications as well as wide range ultra high frequency applications.


The PA-DE34 is a Ferrite based permanent magnet system that features a 1.35 inch (34.4mm) diameter commercially pure aluminum diaphragm assembly. The driver features a mid band output rating of 105dB with a one watt input measured at one meter. This design features P Audio's legendary high temperature systems to ensure both high power handling and high reliability.


The PA-DE34 features an industry standard 1 inch bolt on style exit that allows the driver to easily mate to any high frequency horn with a standard 1 inch bolt on mounting.


Specifications:


  • Throat Diameter: 1 inch (25.4mm)
  • Diaphragm Diameter: 1.35 inch (34.4mm)
  • Nominal Impedance: 8 Ohm
  • Voice Coil DC Resistance: 6.4 Ohm
  • Power Handling: 30 Watt
  • Sound Pressure Level (1W@1M) (Loaded with 90x40 Horn): 105 dB
  • Mounting Type: Bolt On
  • Magnet: Ferrite
  • Diaphragm Material: Aluminium
  • Recommended Crossover: 1.2kHz or higher (12dB/Oct slope)
  • Net Weight: 1.05kg (2.31 lbs)
  • Shipping Weight: 1.1kg (2.42 lbs)
